SINOTRUK Howo TX 6x4 Tipper Truck

Production Year

2025, new truck.

Cabin

TX-F cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver’s seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer,with 4-point support fully floating suspension + shock absorber.High steel bumper, Inter-cooler Protection.

Engine

Diesel 4-stroke direct injection diesel engine

Engine model: WD615.47, 371HP

6-cylinder in-line with water cooling, turbo-charging and intercooling

Displacement:9.726L

Transmission

HW19710, 10F & 2R, with HW50 Direct PTO

Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)

Steering

ZF power steering, model ZF8098, hydraulic steering with power assistance

Front Axle

VGD95, 1*9500 KGS

Steering with double T-cross section beam

Rear Axle

MCP16ZG, 2×16000 KGS

Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.

Ratio:5.92

Propeller Shaft

Double universal joint propeller shaft with gear-shaped coupling flange

Chassis

Front suspension:11semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer

Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer

Brake

Service brake: dual circuit compressed air brake

Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels

Auxiliary brake: engine exhaust brake

Electrics

Operating voltage: 24 V, negative grounded

Starter: 24 V, 5.4 Kw

Alternator: 3-phase, 28 V, 1500 W

Batteries: 2 x 12 V, 165 Ah

Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light

Fuel Tank

300L

Tire

12.00R20, Radial (steel wire) Tires . 10+1 Pics

Cargo body

5400x2300x1450mm. 18 Cubic Meters

Color

Optional

Overall Dimension

8600*2550*3450 mm
